TECHNICAL DATA

Maximum tool diameter:          550 mm
Maximum tool height:              650 mm
Standard original spindle nose:    ISO 50
Special otional adapters :             ISO/HSK
Axis traverse :                           motorized
Micometric axis displacement:  manual
Axis reading resolution:             0,001 mm
Supply voltage:                           380V
Dimensions: 2000 x 400 x 1000 mm
Total weight:                    1000 Kg
